A Mexican’s custome assorted fruit flavor candy box automatic tray packing sealing machine

Short Description:

Original design from Brightwin!

Assorted fruit flavor candy box automatic tray packing sealing machine.This machine consists of two parts,incolud stacking conveyor and the box qutomatic tray packing sealing machine.It different from ordinary boxing machines.

It can finish stacking single products  by arrangement system,and the stacking conveyor transport the fruit flavor candy to the box automatic tray paching sealing machine to finish put the fruit flavor candy  packing wrapped cubes into boxes(24 cubes in each box).


Detail

Product Tags

Layout of the line

https://www.brightwingroup.com/ a-mexicans-custome-assorted-fruit-flavor-candy-box-automatic-tray-packing-sealing-machine .html

This is a customized assorted fruit flavor candy box automatic tray packing sealing machine.Our Brightwin engineers designed the machine themselves,it's our originality product.

This machine consists of two parts,incolud stacking conveyor and the box qutomatic tray packing sealing machine.

The stacking conveyor's system can arrange the assorted fruit flavor candy cubes to be customer requested stacking method, like 3 layers 2 rows and 4 columns or other stacking method.

The customized assorted fruit flavor candy box automatic tray packing sealing machine can automatic feed tray and glue it.At the same time single products are stacked by arrangement system(stacking methed is according to customers' request,can be customized),and then the stacked products are pushed into the glued carton tray.Finally,finished packed products (24 cubes in each box)are transported out by the conveyor.

Process of the line

微信截图_20231103141305

Video

Parameter

Item

Parameter

Product's size

can be customized

Capacity of carton box packing

60-80boes/minute

Capacity of carton tray

10-12trays/minute

Air pressure

0.6-0.8MPa

Power

40KW

Voltage

380V/220V
